Metal Frame Design Prefabricated Storage Warehouse
Qingdao KXD Steel Structure Co,.Ltd,is one of the fore-running company who has been dedicated to the designing, supplying, construction and contracting of various steel structure building projects whether for industrial, commercial, residential and agricultural purpoes with nearly 20 year warranty. KXD was incorporated in the year of 2003 and has also acquired the ISO 9001;2008 and CE certificates. We at KXD pride ourselves on the fact we are one of pioneer general contractor to provide integrated and custom design, engineering, manufacture and installation services for your project.
The below photo is our company Lagos warehouse project:
Prefabricated houses, often referred to as prefab homes or simply prefabs, are specialist dwelling types of prefabricated building, which are manufactured off-site in advance, usually in standard sections that can be easily shipped and assembled. Some current prefab home designs include architectural details inspired by postmodernism or futurist architecture.
Technical Specification
No.
classify
Name
Specification & Parameter
1
Type
standardization
custom made products, design and manufacture according to client' s demand
2
disassembly and assembly
not suitable for assemble and disassemble, lower repeating utilization factor.
3
Specification
Length
No limited, increase expansion joint when length more than 200m.
4
Width
≤ 11m
5
Height:
≤ 3.0m
6
Roof slope:
double slope, 1: 6-1: 4
7
Floors:
1floor
8
Standard
Ground channel
Galvanized steel panel pressure, steel panel thickness is 0.8mm
9
Post
Outdoor post is square steel pipe, material is Q235, components make bottom and surface painted process.
10
roof beam
Triangle roof frame is welded by square steel pipe, components surface is made rust-proof process.
11
purlin
Purlin is square steel pipe, material is Q235, components surface is made rust-proof process.
12
wallboard
75mm~150mm thickness color steel sandwich panel, white color
13
roof board (Ceiling board)
75~150mm thickness color steel sandwich panel, white color
14
roof tiles
V35-125-350 color steel tiles, blue or red color
15
door
sandwich panel door, size: 750mm*2000mm;
16
window
PVC sliding window, conch model
17
Options
ceiling
roof board is also ceiling board, so this house don' t need to make ceiling again.
18
canopy
color steel sheet or color steel sandwich panel canopy
19
door
compound wooden door, security door, aluminium alloy door
20
Electrical accessories
Supply plan, design and construction according to relevant national norms(220V, 50Hz, with lamp, switches and multi-function sockets. )
21
Water plumbing accessories
Supply plan, design and construction according to relevant national norms
