Pre Engineered Metal Building
Created with Pixso. Architecture Standard Prefabricated Steel Structure Frame Workshop

Architecture Standard Prefabricated Steel Structure Frame Workshop

Brand Name: KXD
Model Number: kxd-s0686
MOQ: 200 Square Meters
Price: US$70.00
Payment Terms: T/T,L/C
Detail Information
Place of Origin:
China
Certification:
SGS / ISO/ BV
Flexibility:
Flexible
Sustainability:
Eco-friendly
Corrosion Resistance:
Resistant
Usage:
Construction
Maintenance:
Low
Type:
Building
Cost:
Affordable
Fire Resistance:
Resistant
Weather Resistance:
Resistant
Packaging Details:
Package Size 11900mm * 2300mm * 2500mm
Supply Ability:
10000 Ton Per Month
Highlight:

Architecture Prefabricated Steel Structure

,

Corrosion Resistance Prefabricated Steel Structure

,

Steel Beam pre engineered steel buildings

Product Description
According with Architecture Standard Prefabricated Steel Structure Frame Workshop

ompany Profile

Architecture Standard Prefabricated Steel Structure Frame Workshop 0
Architecture Standard Prefabricated Steel Structure Frame Workshop 1

Ⅰ. Definition and Core Composition

Prefabricated steel structure frame factory buildings are an industrialized building form that uses steel structure components (steel columns, steel beams, steel trusses, etc.).
As the main load-bearing system, the components are prefabricated in the factory and assembled on-site. Its core components include:

Architecture Standard Prefabricated Steel Structure Frame Workshop 2


Basic Info.

Model NO.
kxd-s0686
Usage
Warehouse, Offices, Workshop
Installation
Techinical Guide or Turnkey Projects
Steel Material
GB/Anis/BS/DIN/Uni
Profiles
H /  C / Z / Sectional Steel
Structural Frame
Steel Column, Steel Beam, Steel Truss
Connection
High Strength Bolts
Bolts
Galvanized, Dacromat, Geomet
Coating
Alkyd / Epoxy /Hot-DIP Galvanize
Colors
Custom as Demands
Ventilation
Ridge Ventilator ; Ventilated Fan
Day Light Panel
High Quality Type
Roof / Wall Cladding
Optional (Steel Sheet or Insulated Sandwich Panel)
Insulation
EPS, Glasswool, Rockwool, PU
Crane
Optional (1t ~ 20t)
Door
Security Door, Rolling Shutter, Sliding Door
Transport Package
Seaworthy Package
Specification
SGS / ISO/ BV
Trademark
KXD
Origin
China
HS Code
7308900000
Production Capacity
10000 Ton Per Month

Packaging & Delivery

Package Size
11900mm * 2300mm * 2500mm
Package Gross Weight
22000.000kg


Main Structure

  • Steel components such as H-beams, box-shaped columns and round steel pipes are connected by welding or bolts to form a frame system.

Enclosure System

  • Lightweight materials such as color-coated steel plates and aluminum-magnesium-manganese plates meet the functions of heat insulation, heat resistance and fire resistance.

Bracing System

  • Roof supports and inter-column supports ensure the wind resistance and seismic performance of the structure.

Supporting Systems

  • Modular components for integrating piping, doors and Windows, ventilation and fire protection systems.

Ⅱ. Technical Advantages

Industrialized Production

  • The precision error of the components is ≤2mm, and the factory processing efficiency is increased by more than 50% compared with traditional construction.

Rapid Assembly

  • The on-site installation period is 60% shorter than that of concrete structures. Typical projects (such as a 20,000-square-meter factory building) can complete the main structure construction within 45 days.

Flexible Expansion

  • Horizontal/longitudinal expansion is carried out through bolt connection to adapt to future capacity upgrades.

Green and Low-Carbon

  • The steel recovery rate is ≥90%, construction waste is reduced by 80%, and carbon emissions are 30%-40% lower than those of traditional processes.



Ⅲ. Classification of Application Scenarios

Industrial Manufacturing

  • Mechanical processing workshop, automotive assembly workshop, electronics factory (requiring high-precision temperature and humidity control).

Warehousing and Logistics

  • High warehouse (floor height ≥15m), cold chain logistics center (with insulation and enclosure system).

Energy and Chemical Industry

  • Petrochemical workshops (explosion-proof design), photovoltaic/wind power equipment production workshops.

Emergency Engineering

  • Post-disaster temporary factories, military equipment assembly workshops (with rapid deployment requirements).



Architecture Standard Prefabricated Steel Structure Frame Workshop 3



Ⅳ. Sales

1. Pre-Sales Service: Requirement Diagnosis and Solution Customization, Cost Estimation and Quotation

2. In-Sales Service: Performance Assurance and Process Control (Production Progress, Logistics & Customs Clearance, Quality Control)

3. After-Sales Service: Installation Training, Warranty and Maintenance



Architecture Standard Prefabricated Steel Structure Frame Workshop 4



Architecture Standard Prefabricated Steel Structure Frame Workshop 5



Architecture Standard Prefabricated Steel Structure Frame Workshop 6



1. What type of company are you?

We are a steel structure building manufacturer headquartered in Qingdao, China. We have earned a strong reputation among clients for our professional, warm, and meticulous service. We understand that long-term business relies on strict control over quality, pricing, packaging, delivery timelines, and other key factors.

2. Is your company a factory or a trading company?

We operate as a factory, which allows us to offer you the best and most competitive pricing. Our manufacturing facility spans 150,000 square meters.

3. What quality assurance do you provide, and how do you control quality?

We have established a comprehensive quality control process that inspects products at every stage of production—from raw materials and in-process components to validated/tested materials and finished goods.

4. Can you provide design services?

Yes, we have a team of over 100 design engineers who can create full-solution drawings tailored to your specifications. They use software such as Auto CAD, PKPM, MTS, 3D3S, Tarch, and Tekla Structures (Xsteel) V12.0, among others.

5. Do you offer on-site installation guidance overseas?

Yes, we can provide additional installation, supervision, and training services. We can dispatch professional technical engineers to supervise on-site installations overseas. Additionally, we have our own overseas installation guidance team of over 30 members, with successful project experiences in countries such as France, South Africa, Algeria, Ghana, Gabon, Chile, Hungary, and Australia.

Upon signing the contract, we will provide you with detailed construction drawings and installation drawings. If required, we can also dispatch our engineers to assist with the installation process on-site
