| Brand Name: | KXD |
| Model Number: | KXD-SSW284 |
| MOQ: | 200 Square Meters (MOQ) |
| Price: | US$100.00-200.00 |
| Payment Terms: | L/C,T/T |
Prefabricated steel structure warehouses, with their characteristics of prefabrication, high protection, and easy scalability, provide a full chain solution from design to delivery for global warehousing needs, helping customers achieve dual optimization of storage efficiency and cost.
Ⅰ.Technical parameters and configuration
| System | Details | ||||
| Structural form | Light steel structure (H-shaped steel column beam+C purlin) or container renovation (20GP/40HC box body) | ||||
| Enclosure system | Color steel plate+rock wool sandwich panel (50-150mm), wall can be equipped with 1.2m brick wall skirt to enhance stability | ||||
| Basic requirements | Concrete cushion layer (light steel structure) or strip foundation (container structure), construction period is only 3 days | ||||
| Door and window configuration | Rolling shutter door (width 3-6m)+aluminum alloy window (light transmittance ≥ 70%), supporting electric opening and closing | ||||
| Loading and transportation | 40HC container loading capacity: 150-200 ㎡/box, component classification packaging (rust proof film+wooden pallet) | ||||
Ⅱ. Core advantages of the product
1. Flexible structural selection
• Adopting light steel structure frame or container structure, the single span of light steel structure can reach 24 meters, and the container structure can stack 5 floors to meet the needs of different storage scales.
2. Excellent protective performance
• Waterproof sealing: The roof adopts a combination of EPDM rubber waterproofing membrane and color steel plate, with double waterproofing treatment at the joints, and a leakage rate of ≤ 0.5%;
• Fireproof and Thermal Insulation : Wall and roof can be equipped with 100mm thick rock wool sandwich panels (fireproof grade A, thermal conductivity ≤ 0.04W/(m · K));
• Disaster resistance capability: Wind resistance level of 140km/h (level 12), seismic fortification intensity ≥ 8 degrees, suitable for areas with frequent typhoons and earthquakes.
3. Prefabricated and efficient installation
• All components are prefabricated in the factory (accuracy error ≤ 1mm), assembled with bolts on site, and installed in a 150-200 square meter warehouse in only 5-7 days, which shortens the construction period by 70% compared to traditional processes.
4. Longevity and Economy
• The design life of the main structural steel (Q355B) is ≥ 50 years, and the hot-dip galvanized anti-corrosion layer (thickness ≥ 85 μ m) is maintenance free for 10 years;
• A 40 foot container can load 150-200 square meters of warehouse components, reducing transportation costs by 30% compared to bulk cargo.
Ⅲ. Services
1. Scheme design: Provide drawings (including structural calculations and material lists) within 3 days;
2. Production cycle: 20-30 days (light steel structure)/15 days (container renovation);
3. Delivery guarantee: Provide export customs clearance documents, installation manuals, and 5-year warranty；
4. Installation: Provide on-site assembly guidance or full package installation services (including scaffolding, cranes);
5. Commissioning: Free training for customer teams on basic maintenance skills (bolt tightening, waterproof inspection)；
6. After sales system: 5-year structural warranty+lifetime technical support, regular inspections (bolt tightness, anti-corrosion coating status).
