| Brand Name: | KXD |
| Model Number: | 1.5" |
| MOQ: | 500 pcs |
| Price: | 10-25USD/pc |
| Delivery Time: | 3-6Weeks |
| Payment Terms: | ,T/T |
Square shafts consist of solid square sections ranging from 1.5 inches to 2 inches in size. These piles are primarily designed for ultimate loads between 100 and 650 kN (25-150 kips), although they have been tested to withstand loads exceeding 900 kN (200 kips) in specific circumstances.
Square shaft piles are typically utilized in small to moderate loading applications and offer excellent resistance to tension. They are particularly effective in penetrating dense and cobble-rich soil compared to their helical pipe pile counterparts. However, they exhibit lower resistance to buckling and provide minimal lateral load resistance.
In scenarios where tension is the primary concern, Square Shaft Piers are highly recommended. These piers offer several advantages over standard square shaft anchors, including enhanced stability and greater load-bearing capacity. Their design allows for more efficient installation and better performance in challenging soil conditions, making them a superior choice for applications requiring robust tension support.
Shaft
1.5 inch RCS bar per 1530M or 1045M
Minimum Yield 85 Ksi
Minimum Tensile Strength 100 Ksi
Torque Strength Rating
= 6,700 Ft-lb
Load To Torque Ratio (Kt)
= 10
To Attach To An Extension
Use one 7/8″ A325 Gr. 5 Bolt
Available Nominal Lengths
5′, 7′ and 10.5’
Available Helix Size
8″, 10″, 12″, 14″ & 16″
Helices
A36 Steel with pitch of 3.0″ ± 0.25″
Square Shaft Helical Piles
In applications where tension is the primary consideration, we recommend the Square Shaft Piers. They have several advantages over the typical square shaft anchors.
Square Shaft Advantages:
Composition:
