| Brand Name: | KXD |
| Model Number: | KXD-GI1023 |
| MOQ: | 200 Square Meters |
| Price: | US$35.00-95.00 |
| Payment Terms: | L/C,T/T |
| Standard: | AISI, ASTM, BS, DIN, GB, JIS | Grade: | Q235B/Q355B Carbon Steel |
| Place of Origin: | Shandong, China | Brand Name: | KXD Steel Structure |
| Model Number: | Steel Structures | Type: | Light, Light Steel Structure Frame |
| Application: | Warehouse/Workshop/Sheds/Office Building | Tolerance: | ±3% |
| Processing Service: | Bending, Welding, Decoiling, Cutting, Punching | Product name: | Steel Structure warehouses/workshop/steel building |
| Main structure: | Section Column | Purlin: | C/Z Galvanized Steel(Q235) |
| Surface treatment: | Painting or Galvanizing | Wall&Roof panel: | Steel Sheet or Sandwich Panel |
| Structure type: | Light Portal Frame Structure | Certificate: | ISO9001:2008 |
| Life span: | Up to 50 Years | Wind Resistance: | 181km/h |
Drawings & Quotation
1) Customized design is welcomed.
2) We have an excellent design team. According to the requirements of different projects and clients, we will supply different designs and steel products. In order to give you an exact quotation and drawings,
please let us know the following information. We will quote for you promptly.
Basic design requirements of steel structure workshop.
| Basic Design Requirements | ||
| 1.Project location | 5.Length (sidewall,m) | 9.Window quantity, size |
| 2.Snow load | 6.Width (end wall, m) | 10.Door quantity, size |
| 3.Wind load | 7.Wall Height (eave, m) | 11.Brickwall needed or not. If yes, 1.2m high or 1.5m high |
| 4.Seismic magnitude | 8.Middle column allowed or not | 12.Crane needed or not |
| 13.Thermal insulation. If yes, EPS, fiberglass wool, rock wool, PU sandwich panels will be suggested; If not, the metal steel sheets will be ok. The cost of the latter will be much lower than that of the former. | ||
Engineering Design Software: AutoCAD, PKPM, MTS, 3D3S, Tarch,Tekla Structures(Xsteel)V12.0.etc
Industrial Structural Steel Plant Factory Building Shed Design Price Fabrication Layout Low-Cost Prefab Steel Structure Warehouses.
| MAIN PART | ITEM | SPECIFICATION |
| Main Steel Frame | Steel Beam | Q235/Q345B |
| H shape steel, alkyd/epoxy zinc-rich painting primary painting in twice | ||
| Main Column | Q235/Q345B | |
| H shape steel, alkyd/epoxy zinc-rich painting primary painting in twice | ||
| Wind Column | Q235/Q345B | |
| H shape steel, alkyd/epoxy zinc-rich painting primary painting in twice | ||
| Supporting System | Brace | Q235/Q345B, angle steel or circular steel tube, process and paited |
| Roof Purlin | Q235/Q345B, C or Z shape steel, alkyd painting/hot dip galvanized | |
| Wall Purlin | Q235/Q345B, C or Z shape steel, alkyd painting/hot dip galvanized | |
| Tie Bar | Q235/Q345B, Φ114x3 round steel tube, process and painted | |
| Case Red | Q235/Q345B, Φ12 round steel, process and painted | |
| Roof Cladding | Color corrugate steel sheet, EPS sandwich panel, rock wool, PU, glass wool | |
| Wall Claddding | Color corrugate steel sheet, EPS sandwich panel, rock wool, PU, glass wool | |
| Accessories | Bolts | Ordinary, high strength, stud bolts, anchor bolts |
| Butter | 0.5mm galvanized/prepainted steel plate, stainless steel | |
| Windows | Aluminum alloy-glass, aluminum alloy-shutter, PVC | |
| Doors | Sliding sandwich panel/ steel door, rolling shutter door | |
| Floor Deck | #600, #688, #720, T:0.7-1.2mm thick color corrugated steel plate | |
| Down pipes | VC pipe or steel sheet material or aluminum pipe | |
| Roof Ridge | Color steel sheet | |
| Edge Cover | 0.5mm color steel sheet | |
| Skylighting | FRP light transfer belt | |
| Ventilator | Exhaust fan, ventilation louvers | |
| Crane | Crane in 5 tons to 20 tons | |
| Design Parmameters | Building Size | Length(m)*Width(m)*Eave Height(m) |
| Local Weather | Wind load, Snow load, earthquake magnitude | |
| Roof and wall panel | With or without insulation for roof and wall | |
| Bearing | Make the house resisting heavy wind by 120km/h and 8 grade earthquake | |
| Protection | Color steel sandwich panel has a good fire proof and heat insulation performanc |
| 1 | Location (where will be built? ) _____country, area |
| 2 | Size: Length*width*height _____mm*_____mm*_____mm |
| 3 | Live load on roof(KN/M2), live load on second floor(KN/M2) if have |
| 4 | Wind load (max. Wind speed) _____kn/m2, _____km/h, _____m/s |
| 5 | Snow load (max. Snow height) _____kn/m2, _____mm |
| 6 | Anti-earthquake _____level |
| 7 | Brickwall needed or not If yes, 1.2m high or 1.5m high |
| 8 | Thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels, Corrugated steel sheet with fiber glass wool will be suggested; If not, the Corrugated steel sheet will be ok. The cost of the latter will be much lower than that of the former. |
| 9 | Door quantity & size _____units, _____(width)mm*_____(height)mm |
| 10 | Window quanity & size _____units, _____(width)mm*_____(height)mm |
| 11 | Crane needed or not If yes, _____units, max. Lifting weight____tons; Max. Lifting height _____m |
| 12 | Skylight belt, ventilator and any other accessories if needed. |
