Luxury 2 Floors Steel Frame Buildings Fire Resistance Prefabricated Living House

Name: Luxury 2 Floors Steel Frame Buildings Fire Resistance Prefabricated Living House
Brand: Qingdao KXD Steel Structure Co., Ltd
SKU: kxd-s0594
Price: 250.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: KXD

Certification: SGS / ISO/ BV

Model Number: kxd-s0594

Payment & Shipping Terms

Minimum Order Quantity: 100 Square Meters (MOQ）

Price: US$210.00-290.00

Packaging Details: Package Size 11900mm * 2300mm * 2500mm

Payment Terms: L/C,T/T

Supply Ability: 10000 Ton Per Month

Get Best Price

Chat Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                      2 Floors Steel Frame Buildings, Fire Resistance Steel Frame Buildings, Luxury prefab metal homes


Transportation Method:	Flat-pack/Container	Foundation Type:	Concrete/Steel
Assembly Time:	Short	Fire Resistance:	Class A
Design Style:	Modern/Traditional	Warranty:	30 Years

Transportation Method:	Flat-pack/Container
Foundation Type:	Concrete/Steel
Assembly Time:	Short
Fire Resistance:	Class A
Design Style:	Modern/Traditional
Warranty:	30 Years

Description

Luxury 2 Floors Steel Frame Buildings Fire Resistance Prefabricated Living House

Luxury 2 Floors Simple Design Steel Frame Structural Steel Buildings Prefabricated Living House

Qingdao KXD Steel Structure Co.,Ltd has been an industry leader for prefabricated steel building with preeminence in custom designs and fabrication capabilities.

With more than 30-year-limted warranty in steel building manufacturing and design,KXD's products have been exported to more than 80 countries with good quality and customer service.

Basic Info.

Model NO.

kxd-s0594

Certificate

CE, ISO

Material

Steel Structure

Type

Detached Villa

Installation

Techinical Guide or Turnkey Projects

Steel Material

GB/Anis/BS/DIN/Uni

Profiles

H / I / C / Z / U Sectional Steel

Structural Frame

Steel Column, Steel Beam, Steel Truss

Connection

High Strength Bolts

Bolts

Galvanized, Dacromat, Geomet

Coating

Alkyd / Epoxy /Hot-DIP Galvanize

Colors

Custom as Demands

Ventilation

Ridge Ventilator ; Ventilated Fan

Day Light Panel

High Quality Type

Roof / Wall Cladding

Optional (Steel Sheet or Insulated Sandwich Panel)

Insulation

EPS, Glasswool, Rockwool, PU

Crane

Optional (1t ~ 20t)

Door

Security Door, Rolling Shutter, Sliding Door

Transport Package

Seaworthy Package

Specification

SGS / ISO/ BV

Trademark

KXD

Origin

China

HS Code

7308900000

Production Capacity

10000 Ton Per Month

Component		Specification
Main Steel Frame	Column	Q235, Q355 (Hot Rollled / Welded H Section Steel)
Main Steel Frame	Beam	Q235, Q355 (Hot Rollled / Welded H Section Steel)
Secondary Frame	Purlin	Q235, Q355 C and Z purlin
	Knee brace	Q235 Angle Steel
	Tie Rod	Q235 Circular Steel Pipe
	Brace	Q235 Round Bar
	Vertical and Horizontal Support	Q235 Angle Steel, Round Bar or Steel Pipe
Maintenance system	Roof Panel	Steel Sheet Insulated Sandwich Panel (EPS /Glass-Fiber / Rock-Wool / Pu)
Maintenance system	Wall Panel	Steel Sheet Insulated Sandwich Panel (EPS /Glass-Fiber / Rock-Wool / Pu) Decorative Panel (Glass Curtain, Aluminmum Panel
Accessories	Window	Plastic steel / Aluminium Alloy / PVC Window
	Door	Sliding Door / Electric Rolling Up Shutte / Metal Door / Personal Door
	Rain-spout	PVC
Live load on Roof		In 120kg/Sqm (Color steel panel surrounded)
Wind Resistance Grade		12 Grades
Earthquake-resistance		8 Grades
Structure Usage		Up to 50 years
Temperature		Suitable temperature.-50°C~+50°C
Certification		CE, SGS,ISO9001:2008,ISO14001:2004
Finishing Options		Vast array of colors and textures available
Paint Options		Alkyd painting / Epoxy painting / Hot Dipping Galvanized

Ⅰ. Definition

1. Structural system
-Using a lightweight steel frame as the load-bearing main body, H-shaped steel or box section steel columns and beams are used
-Second floor residential space, with a simple and modern exterior style
2. Construction mode
-Prefabricated production of main structures, walls, floors, and other components in factories
-On site bolt connection assembly, supplemented by a small amount of wet work

Luxury 2 Floors Steel Frame Buildings Fire Resistance Prefabricated Living House 4

Ⅱ. Characteristics

1. Spatial characteristics
-Open layout, no load-bearing wall restrictions (can flexibly separate indoor spaces)
-Large span living/dining room, with cantilevered balcony or terrace on the second floor

2. Technical characteristics
-Integrated kitchen and bathroom system (factory pre installed water supply and drainage pipelines)
-External wall insulation adopts composite sandwich panels (integrated insulation and decoration)

3. Aesthetic characteristics

-Minimalist facade (large glass windows, metal line decoration)
-Light and shadow transparency, emphasizing the integration of indoor and outdoor spaces

Luxury 2 Floors Steel Frame Buildings Fire Resistance Prefabricated Living House 5

Luxury 2 Floors Steel Frame Buildings Fire Resistance Prefabricated Living House 6

Luxury 2 Floors Steel Frame Buildings Fire Resistance Prefabricated Living House 7

Ⅲ. Advantages

1. Construction advantages
-Complete the main construction in 6-8 weeks (traditional buildings take over 6 months)
-Not affected by rainy season, construction error<5mm
2. Performance advantages
-The wind resistance level reaches level 12, and the seismic fortification intensity is 9 degrees
-Superior sound insulation performance (wall sound insulation volume ≥ 45dB)
3. Cost advantage
-The total cost is 20% -30% lower than that of traditional villas of the same area
-Low maintenance cost (steel structure anti-corrosion cycle>25 years)
4. Environmental advantages
-Material recycling rate>90%, reducing construction waste by 80%
-Can be equipped with solar energy systems to achieve zero carbon housing

Ⅳ. Purpose:
1. High end residential properties
-Urban suburban villa
-Holiday homes in the resort area
2. Customized residences
-Designer's own residence
-Artist's studio and residence
3. Investment properties
-Boutique homestay
-High end short-term rental apartments
4. Demonstration of Sustainable Buildings
-Green residential model house
-Zero Energy Residential Exhibition Center

Ⅴ.Service:

We will provide the most perfect service: one-stop service

Luxury 2 Floors Steel Frame Buildings Fire Resistance Prefabricated Living House 11

Luxury 2 Floors Steel Frame Buildings Fire Resistance Prefabricated Living House 12

Luxury 2 Floors Steel Frame Buildings Fire Resistance Prefabricated Living House 13

Luxury 2 Floors Steel Frame Buildings Fire Resistance Prefabricated Living House 14

Luxury 2 Floors Steel Frame Buildings Fire Resistance Prefabricated Living House 15

Luxury 2 Floors Steel Frame Buildings Fire Resistance Prefabricated Living House 16

Luxury 2 Floors Steel Frame Buildings Fire Resistance Prefabricated Living House 17

If you want to know more details, please feel free to contact me at any time
