Product Description
The prefabricated steel structure container house with glass curtain wall is a modern architectural form that integrates multiple features.
1.The steel structure frame of the basic structure
Steel is used as the main structural material, and the main frame of the house is built through processes such as welding and bolt connection. Steel structures have the advantages of high strength, light weight and good seismic performance. They can provide solid and stable support for buildings, and at the same time greatly reduce the self-weight of buildings, making them convenient for transportation and installation.
2.The foundation of container houses
Containers are adopted as the basic unit modules. Containers usually have standardized dimensions and sturdy metal shells, which enables them to be stacked, combined and transported conveniently, providing the basic conditions for the rapid construction and flexible layout of houses.
3.The exterior enclosure structure glass curtain wall
A large area of glass is used as the covering material for the building's exterior walls, and it is fixed to the steel structure main body through a supporting structure system such as a metal frame. Glass curtain walls not only endow buildings with transparency, increasing indoor lighting and creating a bright and spacious visual space effect, but also showcase a modern and fashionable architectural appearance, enhancing the artistic sense and aesthetic appeal of the buildings.
Performance Advantages
1. Prefabricated production and rapid assembly
Adopting a prefabricated container structure, all components are produced in a standardized manner in the factory, making quality easy to control and production efficiency high. Only simple assembly and splicing work is required at the construction site, which greatly shortens the construction period. Compared with traditional construction methods, it can save more than 50% of the time and can be put into use quickly. For commercial offices or exhibition rooms, they can open for business as soon as possible, seize market opportunities and create economic benefits.
2. Significant cost-effectiveness
The production of prefabricated containers has achieved economies of scale and reduced unit costs. Meanwhile, the recyclability of steel structures and the high-efficiency energy-saving performance of glass curtain walls make the energy consumption and maintenance costs of buildings relatively low during long-term use, saving a large amount of operating costs for users and improving the return on investment. It is an economical and practical building solution.
3. Stable and safe structure
Steel structures feature high strength, high toughness and good ductility, capable of withstanding significant wind loads and seismic forces, ensuring the stability and safety of buildings in various harsh environments. Its structural design has been strictly calculated and optimized, conforming to relevant national building codes and standards, providing reliable protection for users.
4. Energy conservation and environmental protection features
The glass curtain wall adopts highly efficient heat insulation, sound insulation and shading technologies, which can effectively reduce the heat transfer between the indoor and outdoor, lower the energy consumption of air conditioning and heating, and at the same time reduce the interference of outdoor noise to the indoor environment, creating a quiet and comfortable indoor environment. In addition, both steel structures and glass curtain wall materials can be recycled and reused, which is in line with the concept of sustainable development and reduces the environmental impact of buildings. It is a green and environmentally friendly architectural form.
Company Profile
Our company offers you various kinds of steel constructions, which would meet all your requirements. Our company are professionally engaged in steel structure design,manutacture and installation. Our specialists have extensive experience in working with different type constructions. Steel constructions are manufactured by using drawing tools, in accordance with customers' all requirements and quality standards.
Our aim is highest quality, competitive price, and best service to satisfy our customers, we will always keep on creating and innovation, build a best credibility and highest reputation company in the world.
Product Parameters
| Detachable Container House (20 feet container) |
| Single Unit Detail |
Length |
5950mm |
| Width |
3000mm |
| Height |
2800mm |
| Weight |
1300kg |
| Roof Live Load |
0.5KN/m² |
| Wind-Resisitance |
0.6KN/m² |
| Seismic Resistance |
8 Grade |
| Fire-proof Grade |
A |
| Service Life time |
10-15 years |
| Installation Time |
4 labors with 3 hours for 1 unit house |
| Max Floors |
3 |
| Loading |
20' Container
(7 units house) |
40' HQ container
(17 units house) |
| Flat Pack Container House (20 feet container) |
| Single Unit Detail |
Length |
6058mm |
| Width |
2438mm |
| Height |
2896mm |
| Weight |
2145kg |
| Roof Live Load |
0.5KN/m² |
| Wind-Resisitance |
0.6KN/m² |
| Seismic Resistance |
8 Grade |
| Fire-proof Grade |
A |
| Service Life time |
15-20 years |
| Installation Time |
4 labors with 2 hours for 1 unit house |
| Max Floors |
3 |
| Loading |
20' Container
(3 units house) |
40' HQ container
(7 units house) |
About the frame connection, detachable container use screws to connect the column and the top/bottom beams. Flat pack container connects the column and the top/bottom beams by welding. So production time of flat pack container is longer than that of detachable container. Relatively speaking, flat pack containers' on-site installation is faster and easier.
Although now detachable contaiber house has good performance, flat pack container house has better performance because it uses a combination of frame + columns.
Combining many advantages of detachable containers house and general containers, flat pack containers have good performance in transport and installation. Further there is little loss after repeated disassembly and transfer. However, the shipping volume of the flat pack container house is still larger. So its sea freight cost is higher. With the product own price, please choose the type as your actual.
Detailed Photos
Packaging&Shipping
The packing method for main steel frame use steel pallet, This method packing can better protect the steel frame, and alos the loading and unloading will be fast and convenient since it could be taken as a whole.(see attached photo). The best advantage can save the quantity of shipping contaier, so it will save the cost of ocean freight, save unlading time and cost.
1.Quality Warranty: Usually, a warranty period of 1 to 2 years is provided. During the warranty period, quality guarantees are given to key parts of the house such as the steel structure main body, waterproofing, anti-corrosion, and fire prevention.
2.Technical Support: The supplier will provide online technical support to answer any questions customers encounter during use, such as the repair and replacement methods of house components.
3.Installation and Training Services: Free installation guidance services are provided, and on-site training is conducted for customers or users to familiarize them with the structure, performance and daily maintenance methods of the house.
4.After-sales follow-up: Regularly conduct after-sales follow-up visits to customers to understand the usage of the house and promptly identify and resolve any potential quality or usage issues.
5. Accessories Supply: We have a long-term supply of various accessories for houses, such as doors and Windows, locks, water and electricity equipment, etc., to facilitate customers' maintenance or replacement when needed.
If you are interested in our products,please contact with us.
