| Brand Name: | KXD |
| Model Number: | KXD-03 |
| MOQ: | 500 sqm |
| Price: | USD 68-100 per sqm |
| Delivery Time: | 25 days |
| Payment Terms: | L/C,T/T |
| Steel Structure Parts:(Q235 or Q355) Hot galvanized or painted | (1). Steel Column: H Section Steel |
| (2). Steel Beam: H Section Steel | |
| (3). Withstand Wind Column: H Section Steel | |
| (4). Connected beam: Circular Tube | |
| (5). Roof Purline:cold formed galvanized C Section Steel or Z Section Steel | |
| (6). Wall purline: cold formed galvanized C Section Steel or Z Section Steel | |
| (7). End Wall purline: C Section Steel or Z Section Steel | |
| Panel Material parts | (1). External Wall panel: (below is selectable) |
| 1) 50mm, 75mm or 100mm thickness EPS sandwich panel | |
| 2) 50mm, 75mm or 100mm thickness Rockwool sandwich panel | |
| 3) 50mm, 75mm or 100mm thickness PU OR FIBER GLASS wool sandwich panel | |
| 4)Corrugated Galvanized Steel sheet with different Color | |
| (2). Internal Wall panel: (below is selectable) | |
| 1)50mm, 75mm or 100mm thickness EPS sandwich panel | |
| 2) 50mm, 75mm or 100mm thickness Rockwool sandwich panel, fiber glass wool sandwich panel or PU sandwich panel | |
| (3). Roofing panel: (below is selectable) | |
| 1)50mm, 75mm or 100mm thickness EPS sandwich panel | |
| 2)50mm, 75mm or 100mm thickness Rockwool sandwich panel | |
| 3)Corrugated Steel Sheet, and insulating layer if need. | |
| 4) 50mm, 75mm or 100mm thickness fiber glass wool or PU sandwich panel | |
| (4). Skylight: 820# Glass Fiber Reinforced Plastics (FRP) | |
| Door and Window | (1). External Door ( Rolled up door or Sliding door ) |
| -1. Sandwich panel Sliding Door with double open | |
| -2. Galvanized steel opening by power-operated Roller Door | |
| (2). Internal Door: | |
| 50mm Thickness EPS sandwich panel with aluminum alloy door frame | |
| (3). Window: | |
| PVC Window or aluminum alloy window frame with glass. | |
| Drainage parts | (1).Galvanized water channel: |
| 2mm thickness galvanized steel water channel @ 3000mm or 2440mm/pcs | |
| (2). Down spout: ∅110 PVC Down spout with Accessorie | |
| Connecting Piece | (1) Purline draw bar: ∅12 |
| (2) Horizontal Bracing: ∅24 Circular Tube | |
| (3) Knee-Bracing: L Steel | |
| (4) Purline Drive pipe: Φ32*2 | |
| (5) Column Bracing: ∅24 Circular Tube |
| Size | length, width, eave height and ridge height? |
| Climate | wind speed, snow load, temperature, which city will you build in? |
| Roof panel material | EPS sandwich panel, fiber glass wool sandwich panel, rock wool and PU sandwich panel, or corrugated steel sheet, which you like more? |
| Wall panel material | EPS sandwich panel, fiber glass wool sandwich panel, rock wool and PU sandwich panel, or corrugated steel sheet, which you like more? |
| Window or door | The size and quantity, any special requirement please? |
| Other need or not | Gutter, downpipe, skylight, fans, or whether there is a crane? if yes, what's the loading weight of the crane? |
