| Brand Name: | KXD-SSW1059 |
| Model Number: | KXD-SSW1059 |
| MOQ: | 200 Square Meters (MOQ) |
| Price: | US$50.00-100.00 |
| Delivery Time: | 30days |
| Payment Terms: | T/T |
The Steel Structure Prefabricated Metal Building (SS-331) is a large-span or multi-span steel structure warehouse and prefabricated metal building. It is widely used for steel structure workshops, warehouses, and all kinds of steel buildings.
The following parameters are required for design and customization:
High-strength bolts, common bolts and nuts, self-tapping screws, foundation bolts and nuts, etc.
30% T/T before production; the balance before shipment.
We look forward to building a successful business relationship with you.
| Material | Specification |
|---|---|
| Length | With customer's requirement |
| Width | Single span, double-span, multi-span |
| Height | With customer's requirement |
| Column | Q235, Q345 welded H-section steel |
| Beam | Q235, Q345 welded H-section steel |
| Purlin | Q235 C channel or Z channel |
| Knee brace | Q235 angle steel |
| Vertical and transversal support | Q235 angle steel, round bar, or steel pipe |
| Tie bar | Q235 steel pipe |
| Brace | Q235 round bar |
| Cladding system | EPS, PU, fiber glass, and rock wool sandwich panels or corrugated steel sheet with fiber glass wool insulation. Available in different colors and gauges. |
| Partition wall | Sandwich panels (EPS, PU, fiber glass, rock wool, etc.) available in different colors and gauges. |
| Door | Sandwich panel sliding door or roller door |
| Gutter | Stainless steel or color steel sheet |
| Rainspout | PVC |
| Live load on roof | 120 kg/m² (color steel panel surrounded) |
| Wind resistance grade | 12 grades |
| Earthquake resistance | 8 grades |
| Structure usage | Up to 50 years |
| Finishing options | Vast array of colors and textures available |
| Paint options | Alkyd painting, two primary paintings, two finish paintings (gray paint, red paint, white paint, epoxy zinc, etc.), or galvanized. |
