Modular Container
Created with Pixso. 20ft Expandable Container House Dual Wings Mobile Villa for Park Courtyard Kitchen

20ft Expandable Container House Dual Wings Mobile Villa for Park Courtyard Kitchen

Brand Name: KXD
Model Number: KXD-35S
MOQ: 5 sets
Price: USD 6000-8000
Delivery Time: 25 day
Payment Terms: L/C,T/T
Detail Information
Place of Origin:
Qingdao,China
Certification:
CE/ISO
Customization:
Available
Delivery Method:
2 Units Per 40HQ Shipping Container
Roof:
EPS/Rock Wool/PU Sandwich Panel
Installation:
Easy And Fast
Durability:
High
Sustainability:
Eco-friendly
Packaging Details:
seaworthy package
Supply Ability:
10000 sets/month
Highlight:

20ft expandable container house

,

dual wings mobile villa

,

expandable container home for park

Product Description

20ft Expandable Container House Dual Wings Mobile Villa for Park Courtyard Kitchen

Basic info.


Design Style Modern After-sale Service Online technical support
Material Metal, Steel Shape Rectangle
Feature Breathable Product Type Container house
Warranty 1 year Application living container house, Villa, Leisure Facilities, Warehouse, Park, Courtyard, Outdoor
Product name Expandable Container Color Customized Colors


Product Description


  • Energy Efficiency: Adopts new energy, energy-saving lighting, composite walls and other energy/water/material/land-saving technologies for integrated design.
  • Structure: Steel frame main structure + detachable insulated enclosure panels; connected by bolts, simple and quick to install.
  • Assembly, Dismantling & Reusability: 20+ years service life, recyclable without damage; metal inner walls with strong stain resistance, ideal for secondary relocation.
  • Layout: Modular design, freely combinable within container size to meet diverse space and shape needs.
  • Application: Highly prefabricated modules, deployable quickly and economically for temporary, semi-permanent or permanent buildings.

Product Advantages

  • Safety & Comfort: Materials meet national standards (earthquake-resistant Grade 8, wind-resistant Grade 10, fire-resistant Class A); spacious, bright, well-ventilated, soundproof and insulated.
  • Eco-friendliness & Energy Efficiency: Zero construction waste; 80% shorter construction period, 70% less labor, 98% less concrete loss, 70% less water use, and over 50% overall energy saving vs. traditional buildings.
  • Easy & Quick Installation: Movable and reusable; standard steel-welded units connected by bolts.
  • Integrated Customization: Factory-produced modular units (usable alone or combined horizontally/vertically, stackable); suitable for dormitories, offices, tourism camps, exhibition halls, hotels, schools, shops, etc

Product Parameters


20 foot expandable container house configuration parameters




basic feature
Product model
20 foot
House type
Open room
Expand size
L5900*W6200*H2480
Number of guests
2-4 people
Internal
dimensions

L5640*W6040*H2040
Electric
power
consumption

12KW
Folding size
L5900*W2200*H2480
Total net weight
2.8T
area covered
37 m²
Frame structure
name
content
Specifications


Main frame
(fully
galvanized)
Top side beam
80*100*2.5mm square tube
Top beam
Bending part 2.0mm
bottom side rail
80*140*3mm square tube
Bottom beam
Bending part 2.0mm
Galvanized
suspension
head
Galvanized suspension head 210*150*160*4.0
Steel column
Bending part 3.0mm
Side wing
frame (fully galvanized)
Top frame
40*80*1.5mm P-type pipe
40*80*1.5mm square tube
Bottom frame
60*80*1.5mm square tube
Folding hinges
130mm galvanized hinges
Overall
framework
protection coating

spray

Electrostatic spraying/direct plastic powder

Box top
External roof panel
T50mm EPS color steel plate+Waterproof coating
Internal ceiling panel
200 type ceiling panel

wallboard
Side walls,
front and rear
T65mm EPS color steel plate
Internal
partition board
T50mmEPS color steel plate
ground
Main frame
Fireproof cement fiber floor 18mm thick
both wings
Bamboo plywood 18mm thick

doors and windows
Plastic steel sliding window
920*920mm
Steel single door opening
840*2030mm






electrical system
Circuit breaker system
One 32A leakage protector;Voltage 220V,50HZ
lamp
Bull 30*30 flat panel light,large ceiling light

Socket
Standard international three hole and five hole sockets
(socket standards can be configured according to
customer needs)
Lamp switch
Double open,single key switch(switch standard can
be configured according to customer needs)

wiring
6 square meters of incoming lines,4 square meters of air conditioning sockets,2.5 square meters of regular
sockets,and 1.5 square meters of lighting.
(Circuit that meets certification requirements can be customized according to the country)
Number of
containers
loaded
2 sets in a 40 foot high container


20ft Expandable Container House Dual Wings Mobile Villa for Park Courtyard Kitchen 0

20ft Expandable Container House Dual Wings Mobile Villa for Park Courtyard Kitchen 1

20ft Expandable Container House Dual Wings Mobile Villa for Park Courtyard Kitchen 2


20ft Expandable Container House Dual Wings Mobile Villa for Park Courtyard Kitchen 3

FAQ:
1. Q: What is the advantage of this container house compare with the traditional brick house?
A: Long lifetime;Green and energy saving, Good earthquake proof; Fast and easy to install etc...
2. Q: What is life span of your houses?
A: The durable for structure is more than 15 years .
3. Q: What is the maximum storey for this kind of house?
A: 3 storey due to the shipping container house loading limit.
4. Q: How many days needed to install the hosue?
A: A team of 3 experienced workers can install two per day.
